AFL-xxx-9103 Panel PC
Page 12
SPECIFICATION AFL-12B-9103-R10
Resolution 1024 x 768
Active Area (mm) 245.76 x 184.32
Pixel Pitch (mm) 0.24 x 0.24
LCD Color 262K
View Angel (H/V) 120/100
Brightness (cd/m
2
) 400
Contrast Ratio 500:1
Supply Voltage (V) 3.3 V
Backlight 2 CCFL
Backlight MTBF (hrs.) 50000
Dimensions (WxHxD)(mm) 278.3 x 209.0 x 12.0
Table 1-5: AFL-12B-9103-R10 TFT LCD Monitor Specifications
1.4.5 Touch Screen Specifications
The AFL-xxx-9103 series come with an analog resistive type touch panel. Table 1-6 lists
the touch panel specifications.
SPECIFICATION AFL-10A-9103-R10 AFL-12B-9103-R10
Model 75200-1104502A-RS 75200-1121505B-RS
Type Analog Resistive Type Touch Panel
Wire Type 5-wire
Viewing Area (mm) 219.8 x 166.8 188.0 x 250.0
Active Area (mm) 212.1 x 159.3 185.0 x 246.0
Total Transmission 78%
Maximum Voltage DC 7 V
Connector Type FPC.
Operating Temperature -10°C ~ 50°C
Operating Humidity 20% ~ 90% RH
Storage Temperature -20°C ~ 70°C
Storage Humidity 20% ~ 90% RH
