IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 38
The PS/2 connector connects to a PS/2 keyboard and mouse.
PIN DESCRIPTION
1 VCC5
2 MOUSE DATA
3 MOUSE CLK
4 KEYBOARD DATA
5 KEYBOARD CLK
6 GND
Table 2-17: PS/2 Keyboard & Mouse Connector
2.11.18 Battery Connector
CN Label: CN1
CN Type:
4-pin box header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-18
The battery connector connects to the system battery. The system battery provides power
to retain basic settings and the system clock.
PIN DESCRIPTION
1 +12 V
2 +12 V
3 GND
4 GND
Table 2-18: Battery Connector
2.11.19 Fan Connector
CN Label: FAN1
CN Type:
3-pin wafer
CN Location:
See
Figure 2-9
