IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 39
CN Pinouts:
See
Table 2-19
The fan connects to a system fan. The system fan provides cooling for the computer. The
fan speed is read by the computer and then adjusted according to temperature and fan
settings.
PIN DESCRIPTION
1 Fan Speed Detect
2 +12 V
3 GND
Table 2-19: Fan Connector
2.11.20 LVDS Connector
CN Label: LVDS2
CN Type:
30-pin crimp
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-20
The LVDS connector connects to the LCD panel and provides the data for the display of
images on the screen.
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 LVDSB0+ 4 LVDSB0-
5 LVDSB1+ 6 LVDSB1-
7 LVDSB2+ 8 LVDSB2-
9 LVDSBCLK+ 10 LVDSBCLK-
11 LVDSB3+ 12 LVDSB3-
13 GND 14 GND
15 LVDS0+ 16 LVDSO-
17 LVDS1+ 18 LVDS1-
19 LVDS2+ 20 LVDS2-
21 LVDSCLK+ 22 LVDSCLK-
