IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 36
The COM1 serial port connector provides an RS-232 data connection to attached devices.
PIN DESCRIPTION
1 DCD1
2 RX1
3 TX1
4 DTR1
5 GND
6 DSR1
7 RTS1
8 CTS1
9 RI1
Table 2-14: COM1 Serial Port Connector
2.11.15 SATA Ports
CN Label: SATA1
CN Type:
SATA connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-15
The SATA connector connects to SATA hard drives and SATA CD-ROMs.
PIN DESCRIPTION
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
8 GND
9 GND
