AFL-xxx-9103 Panel PC
Page 34
PIN DESCRIPTION
1 Line-out-L
2 GND
3 GND
4 Line-out-R
Table 2-10: Audio Output Connector
2.11.11 Microphone Input Connector
CN Label: MIC1
CN Type:
2-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-11
The microphone input connector connects to a microphone for audio input.
PIN DESCRIPTION
1 MIC_IN
2 GND
Table 2-11: Microphone Input Connector
2.11.12 12 V Power Connector
CN Label: CN7
CN Type:
3-pin box header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-12
The 12 V power connector provides 12 V of power to connected devices.
PIN DESCRIPTION
1 12 V
2 GND
