IEI Technology AFL-xxx-9103 User Manual

AFL-xxx-9103 Panel PC
Page 31
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-6
The backlight connector provides power for the LCD panel backlight.
PIN DESCRIPTION
1 INV VCC
2 INV VCC
3 LCDBKTCT
4 Brightness
5 GND
6 GND
Table 2-6: Backlight Connector
2.11.7 VGA Connector
CN Label: CN6
CN Type:
10-pin box header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-7
The VGA connector can connect to an external monitor.
PIN DESCRIPTION PIN DESCRIPTION
1 RED 2 DDCDAT
3 GREEN 4 DDCCLK
5 BLUE 6 GND
7 VSYNC 8 GND
9 HSYNC 10 GND
Table 2-7: VGA Connector
