AFL-xxx-9103 Panel PC
Page 10
SPECIFICATION AFL-10A-9103-R10 AFL-12B-9103-R10
Power 12 V, 60 W DC power adapter
Power Consumption 41 W 46 W
Mounting Feature Panel, Rack, Wall, Arm, Stand
Operating Temperature 0ºC ~45ºC
Storage Temperature -20ºC ~60ºC
Relative Humidity 10% ~ 80% RH, non-condensing
Dimension (W x H x D) 276 x 226.9 x 50.7 304 x 246 x 56
Net Weight 1.4 kg 1.8 kg
Front Panel Protection IP 64 compliant
Safety & EMI CE / FCC / CCC / UL / CB
Table 1-2: System Specifications
1.4.3 Motherboard Specifications
The AFL-xxx-9103 series come with an AFLMB-9103GME motherboard. The technical
specifications of the motherboard are listed in
Table 1-3.
Specification AFLMB-9103GME
CPU Intel® Celeron
Chipset Intel® 910GMLE and Intel® ICH6M
Display CRT integrated in Intel® 910GMLE
Supports panel resolution from VGA to UXGA (1400 x 1050)
Supports one Dual-Channel LVDS panel
Memory Supports one 200-pin 400 MHz DDR2 SDRAM SO-DIMM module up
to 2.0 GB
Extension One PCIe Mini slot
BIOS AMI BIOS
SSD CompactFlash®
Super I/O ITE8712F
Audio Realtek RTL ALC888 (High Definition Audio), with TDA1517
LAN Realtek RTL8111CP PCIe Gigabit Ethernet
COM 1 x RS-232 serial port
1 x RS-232/422/485 serial port
