5 - ADJUSTMENTS AND SETTING-UP BOSS 332/545/552 HD
5 - Pag. 14 / 34
Remove the front half bushes in the following
way:
BOSS 332
• Remove the cover and manually extract the two
half bushes.
BOSS 545/552-HD
• Remove the cover, fully open the two half
bushes by manually turning the shaft "A" and
extract the lower bush
• Close the remaining half bush by acting on the
shaft "A", and extract it.
Only for BOSS 332
• Remove the internal sleeve.
