Intermec EasyCoder PM4i User Manual

Appendix A — Technical Data
124 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Printing
Print Technique Direct and Thermal
Tr a n s f e r
Printhead Resolution 8 dots/mm (203.2
dpi)
Option 300 dpi
Print Speed (variable) 100 to 200 mm/sec.
(4 to 8 in/sec.)
100 to 150 mm/sec.
(4 to 6 in/sec.)
8 dots/mm
300 dpi
Print Width (max) 104 mm (4.095 in)
105.7 mm (4.161 in)
8 dots/mm
300 dpi
Print Length (max) 32767 dots = 409.5
cm (161.25 in)
Media Width (min/
max)
25 to 114.3 mm (1 to
4.5 in)
Media Roll Diameter
(max)
213 mm (8.38 in)
Media Roll Core
Diameter
38 to 40 mm (1.5 in)
or 76 mm (3 in)
Ribbon Width (min/
max)
25 to 110 mm (1 to
4.33 in)
Ribbon Roll
Diameter (outer),
max.
82 mm (3.2 in) 450 m (1475 ft) of
ribbon
Ribbon Roll Core
Diameter (inner)
25.4 mm (1.00 in)
Print Directions 4
Modes of Operation
Tear-Off (Straight-
through)
Yes
Peel-Off (Self-strip) Option
Cut-Off Option With cutter

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
