Intermec EasyCoder PM4i User Manual

Appendix A — Technical Data
126 EasyCoder PM4i Printer User’s Guide (Fingerprint Version)
Sensors
Label Gap/Black
Mark/
Out of Media
Yes Variable position
Printhead Lifted Yes
Ribbon End/Ribbon
Low
Yes
Paper sensor Option
Controls
Control Lamps 3
Display 2 × 16 character LCD Background light
Keyboard 22 keys membrane-
switch type
Feed/Pause button 1
Beeper Yes
Data Interfaces
Serial 1 × RS-232 + 1 ×
USB
Bar Code Wand Yes
Connection for
Optional Interface
Boards
1 + 2 1 for EasyLAN
2 for other boards
Finisher Interface 1 For cutter etc.
Memory Card
Adapter
1Compact Flash cards
Accessories and Options
Special Printheads 8 dots/mm (202.3
dpi): 2 types
11.81 dots/mm (300
dpi): 2 types
See Chapter 9
Integral Self-strip
Unit with Liner
Takeup
Option For peel-off operation

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
