Intermec EasyCoder PM4i User Manual

Chapter 7 — Setup Mode
EasyCoder PM4i Printer User’s Guide (Fingerprint Version) 71
Buttons Functions
Move one menu to the left on the same level or
scroll back in a stack of options.
1
Move up one level.
1
Move one menu to the right on the same level
or scroll forward in a stack of options.
1
Move down one level.
1
Display error messages at test label printing
failure.
Enter numeric values.
Specify negative values (leading position).
Clear displayed values.
Acknowledge and move to next menu or
perform testfeeds in the Testfeed menu, or print
test labels in the Test label menu.
Exit the Setup Mode. Can be used anywhere in
Setup Mode.
1 “Left”, “right”, “up”, and “down” refer to the overviews later in this
chapter.
-

Intermec EasyCoder PM4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Display	LCD
Product color	Silver
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.5/8.7 mm
Maximum label width	114.3 mm
Maximum label length	4 m
Maximum roll diameter	213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	15 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	543 mm
Width	298 mm
Height	261 mm
Weight	13500 g
