Unisab III HMI menu tree
Bold text = menu
Normal text = a selectable picture
Menu level 1 Menu level 2 Menu level 3 Menu level 4
Favourites Default
User 1
User 2
User 3
User 4
User 5
User 6
Manage
favourites
Alarms
Shutdown
Table 1: Unisab III HMI menu tree
Unisab III control
Engineering manual - Unisab III 1.10
001930 en 2014.09
19/319
