Juniper SRX300 Series Reference Guide
5
of 1
of 1 rating
142 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Table
56:
Channels
Supported
on
the
5
GHz
Radio
(20
MHz
Bandwidth)
Center
Frequency
MHz
Channel
Number
Band
5180
36
5150~5250
MHz
5200
40
5220
44
5240
48
5260
52
5250~5350
MHz
5280
56
5300
60
5320
64
96
93
95
Table of Contents
Default Chapter
3
Default Chapter
3
Table of Contents
3
About the Documentation
8
Documentation and Release Notes
8
Using the Examples in this Manual
8
Merging a Full Example
9
Merging a Snippet
10
Documentation Conventions
10
Documentation Feedback
13
Requesting Technical Support
13
Self-Help Online Tools and Resources
14
Creating a Service Request with JTAC
14
Overview
15
SRX300 Series and SRX550M Interface Modules Support
17
SRX300 Series and SRX550 High Memory Services Gateway Interface Overview
17
SRX300 Series and SRX550 High Memory Services Gateway Mini-Physical Interface Modules Overview
17
SRX300 Series and SRX550 High Memory Services Gateway Gigabit-Backplane Physical Interface Modules Overview
18
Interfaces Port Naming Conventions for the SRX300 Series and SRX550 High Memory Services Gateways
20
SRX300 Series and SRX550 High Memory Services Gateway Interface Modules and Compatibility
21
MTU Default and Maximum Values for Physical Interface Modules
22
Power over Ethernet Support on SRX550 High Memory Services Gateway Interfaces
24
SRX300 Series and SRX550 High Memory Services Gateway Interfaces Power and Heat Requirements
25
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R)
26
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Overview
27
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Hardware Specifications
27
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Leds
28
1-Port Serial Mini-Physical Interface Module Interface Cables
28
EIA-530A DCE and DTE Cable Pinouts
29
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
29
EIA-530A DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
31
RS-232 DCE and DTE Cable Pinouts
32
RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
32
RS-232 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
33
RS-422/449 (EIA-449) DCE and DTE Cable Pinouts
34
RS-422/449 (EIA-449) DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
35
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
36
V.35 DCE and DTE Cable Pinouts
38
V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
38
V.35 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
39
X.21 DCE and DTE Cable Pinouts
40
X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
41
X.21 DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module
41
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R) Basic Configuration
42
Using the J-Web Interface
43
Using the CLI
44
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R)
44
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Overview
45
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Hardware Specifications
46
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Leds
46
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Supported Loopback Diagnostics
47
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Network Interface Specifications
48
Cable Specifications and Pinouts
49
Connector to RJ-48 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R)
49
Connector to DB-15 Connector Pinouts for the 1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R)
50
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Basic Configuration
52
1-Port VDSL2 Annex a Mini-Physical Interface Module (SRX-MP-1VDSL2-R)
55
1-Port VDSL2 Annex a Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Overview
55
1-Port VDSL2 Annex a Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Hardware Specifications
56
1-Port VDSL2 Annex a Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Leds
57
1-Port VDSL2 Annex a Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Supported Profiles
57
1-Port VDSL2 Annex a (SRX-MP-1VDSL2-R) Mini-Physical Interface Module Cable Specifications
58
1-Port VDSL2 Annex a Mini-Physical Interface Module (SRX-MP-1VDSL2-R) Basic Configuration
59
Using the J-Web Interface
59
Using the CLI
60
8-Port Gigabit Ethernet SFP XPIM
61
8-Port Gigabit Ethernet SFP XPIM Overview
61
8-Port Gigabit Ethernet SFP XPIM Components
62
8-Port Gigabit Ethernet SFP XPIM Hardware Specifications
63
8-Port Gigabit Ethernet SFP XPIM Leds
63
8-Port Gigabit Ethernet SFP XPIM Supported Transceivers
64
8-Port Gigabit Ethernet SFP XPIM Network Interface Specifications
65
8-Port Gigabit Ethernet SFP XPIM Basic Configuration
67
16-Port Gigabit Ethernet XPIM (Poe)
69
16-Port Gigabit Ethernet XPIM (Poe) Overview
70
16-Port Gigabit Ethernet XPIM (Poe) Components
71
16-Port Gigabit Ethernet XPIM (Poe) Hardware Specifications
71
16-Port Gigabit Ethernet XPIM (Poe) Leds
72
16-Port Gigabit Ethernet XPIM Basic Configuration
73
LTE Mini-Physical Interface Module
73
LTE Mini-Physical Interface Module Leds
77
LTE Mini-Physical Interface Module Hardware Specifications
78
LTE Mini-Physical Interface Module Installation and Configuration
78
Installing the LTE Mini-PIM
79
Configuring the LTE Mini-PIM
83
Firmware Upgrade on the LTE Mini-Physical Interface Module
84
Mini-PIM Firmware Upgrade Using the CLI
84
Modem Firmware Upgrade through Over-The-Air (OTA)
86
Wi-Fi Mini-Physical Interface Module
88
Wi-Fi Mini-Physical Interface Module Overview
89
Front Panel Components
89
Wi-Fi Mini-PIM Models
90
Physical Interface
91
Wi-Fi Mini-PIM Hardware Specifications
91
Antenna Specifications
92
Channels and Frequencies Supported on the Wi-Fi Mini-PIM
92
Dynamic Frequency Selection
96
Country Codes and Regulatory Domains
97
RF Specifications for the Wi-Fi Mini-PIM
107
Installing the Wi-Fi Mini-PIM in an SRX Series Services Gateway
109
Configuring the Wi-Fi Mini-PIM on an SRX Series Services Gateway
111
Wi-FI Mini-PIM Configuration Overview
112
Radio Configuration Overview
112
Virtual Access Point Configuration Overview
113
Configure the Wi-Fi Mini-PIM
115
Verify the Status of the Wi-Fi Mini-PIM
118
Upgrading the Firmware on the Wi-Fi Mini-PIM
120
Maintaining Interface Modules
124
Maintaining the SRX Series Interface Modules
126
Required Tools and Parts for Replacing Interface Modules
126
Preventing Electrostatic Discharge Damage to the SRX300 Series and SRX550 High Memory Services Gateway
128
Replacing Mini-Physical Interface Modules on the SRX300 Series and SRX550 High Memory Services Gateways
128
Removing a Mini-Physical Interface Module
128
Installing a Mini-Physical Interface Module
130
Removing a Blank Mini-Physical Interface Module Faceplate
131
Installing a Blank Mini-Physical Interface Module Faceplate
131
Removing a Gigabit-Backplane Physical Interface Module
132
Installing a Gigabit-Backplane Physical Interface Module
133
Removing a Blank Gigabit-Backplane Physical Interface Module Faceplate
134
Installing a Blank Gigabit-Backplane Physical Interface Module Faceplate
134
Contacting Customer Support and Returning the Module
136
Returning the SRX Series Modules
138
Contacting Customer Support
139
Return Procedure for SRX Series Services Gateway Hardware Components
140
Locating the SRX Series Services Gateway Hardware Component Mini-PIM or GPIM Serial Number Label
141
SRX Series Services Gateway Mini-PIM Serial Number Label
141
SRX Series Services Gateway GPIM Serial Number Label
141
Required Tools and Parts for Packing the SRX Series Services Gateway Hardware Components
141
Packing the SRX Series Services Gateway Hardware Components for Shipment
141
Packing the Hardware Components for Shipment
141
Other manuals for Juniper SRX300 Series
User Manual
128 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Juniper SRX300 Series and is the answer not in the manual?
Ask a question
Juniper SRX300 Series Specifications
General
Memory
4 GB
CPU
Intel Atom
Storage
8 GB
Operating Temperature
32°F to 104°F (0°C to 40°C)
Humidity
10% to 90% noncondensing
