Kaye Validator AVS - System Specifications

Appendix B. Environmental Compliance
DRAFT
B.2.3. System Specifications
Total System Specifications
When you use specifications to compare equipment, be sure to establish an error budget that
accounts for all possible measurement uncertainty. Sensor calibration is an integral part of
validation, and total system accuracy should include potential error from the recorder, as well
as the temperature reference and traceable standard. Since all component errors are additive to
the total system, every potential error is significant. A summary of the error budget for a
validation system after sensor calibration with type T thermocouples, used at steam and dry
heat with a Kaye HTR-400 as temperature reference and a Kaye IRTD-400, is listed below.
Kaye Validator AVS (resolution and short term stability)
0.017°C
k=1
IRTD Temperature Standard (IRTD-400)
0.013°C
k=1
Temperature Reference (HTR-400 @121°C)
0.051°C
k=1
Accumulated Uncertainty (Route Sum Square)
0.055 °C
k=1
Total System Uncertainty
0.11°C
k=2
Kaye Validator AVS Specifications
Analog Input
Up to 48
Voltage Input Accuracy
30 days: ±(0.003% of reading + 2 counts + 4 microvolts)
1 year: ±(0.006% of reading + 2 counts + 4 microvolts)
System accuracy with thermocouple
(specified from 20 to 30°C for 30days)
±(0.003% of reading + 0.25°C)
System accuracy with thermocouple
(specified from 0 to 50°C for 30days)
±(0.028% of reading + 0.56°C)
Sensitivity
0.5 microvolts/count on most sensitive range
Voltage Temp. Coef.
±(0.1 microvolts + 0.001% reading)/°C
Compensator Temp. Coef.
±0.01°C per °C
Input Terminal Temperature
Non-uniformity
±0.1°C from calibrated terminal
Input Ranges
-6 to 30mV, -12 to 60mV, -60 to 300mV, -2 to 10V
Environmental
Temperature: 0 to 50°C (32 to 122°F)
Relative humidity: 95% non-condensing
Power
90 to 250 VAC, 50/60 Hz
Fuse Rating
4A Slow Blow
Size
190H X 411W X 381 mm D (457 mm with SIM)
7.5 in H x 16.2 in W x 15 in D (18 in with SIM)
Weight
10.60 kg (23.4 lbs)
Battery
Lithium ion with minimum 60 minutes of battery backup
