6. Engine Removal;In
spection & Installation
6-56
12.
2The figure shows flange surface nut torque to300.N.m
1
Driven shaft block 6 C form block circle
2
Bearing plate 7 Axle drive bevel pinion
3
Hexagon flange boltsM6*22
torsion10N.m
8 washerΦ16*Φ32*2
4
driven shaft 9 Flange facingnutM16 torsion300N.m
5
Bridge driven gear
