6. Engine Removal;In
spection & Installation
6-67
1
Pump impeller components 12
Hexagon flange boltsM6*20
torsion10N.m
2 copper
packingΦ7*Φ12*2 13 Shift shaft assembly
3
Flange surf
ace nut covered formM7
torsion10N.m
14 locating pinΦ8*10
4
water Pump cover gasket 15 Shift shaft cover gasket
5
water pump cover 16 Shift shaft cover
6
Hexagon flange boltsM6*28
torsion10N.m
17
Hexagon flange boltsM6*139
torsion10N.m
7 exhalent
siphon 18
Hexagon flange boltsM6*28
torsion10N.m
8
The pipe clip 19 locating pinΦ6*12
9
Shift gears pulled move 20 Right box gasket
10 washerΦ6*Φ19*1.5
21 Right box combination
1
1 spring washer 6mm 22
Hexagon flange bolts M6*30
torsion 10N.m
6
