KEEWAY 500ATV - Page 130

6. Engine Removal;In
spection & Installation
6-68
1 oil
inlet 6 The tubing A
2
T
ubing bolt M12*30
torsion 35N.m
7
Tubing bolt M10*28
torsion 35N.m
3 copper
packingΦ12*18*1.5 8
Tubing bolt M12*43
torsion 35N.m
4 copper
packingΦ10*Φ18*1.5 9
Hexagon flange bolts M6*28
torsion 10N.m
5
The tubing B 10 oil sealΦ25*Φ47*13
