KEEWAY 500ATV - Page 81

6. Engine Removal;In
spection & Installation
6-19
2.1
. As shown in figure remove the right cover
hex flange bolts
2.2 . As shown in figure remove the right cover
Hex flange bolts
2.3 Turn the handwheel chronological, make the
flywheel scribed line and coil fixed a carved on
the line alignment.
6
