6. Engine Removal;In
spection & Installation
6-20
2.4
As shown in figure remove the flywheel M16 nuts.
2.5 As shown in figure loaded on the flywheel dial is taken
2.6 Have the rem
ove the flywheel
2.6.1．With specialized tools into the
flywheel remove screw of screw hole,
and by pneumatic wrench tighten the
special tools will flywheel ejector.
matters need attention；
2.6.2. Special tools for three bolt twist into
depth to consistent, and try to twist the end.
