6. Engine Removal;In
spection & Installation
6-34
2. Check valve diam
eter measurement.
4.10 L
ock shaft check
Lock shaft diameter standards：21.73-21.84 mm
● If the test result is less than standard
requirements, the replacement lock shaft.
4.11. Camshaft check
●Check the camshaft inlet CAM and CAM face whether exhaust pitting or potholes defect, if have,
replace the camshaft
1. Inlet CAM standard height：32.769 mm
min-height ：32.659 mm
