Model 2701 User’s Manual
Triggering
8-9
V
oltmeter complete
The
VMC output pro
vides a TTL-compatible output pulse that can be used to trigger other
instruments. The specifications for this trigger pulse are sho
wn in
Figure 8-5
. T
ypically
,
you would want the Model 2701 to output a trigger after the settling time of each
measurement.
Figure 8-5
T
rigger link output pulse specifications (VMC)
Meter
Complete
TTL High
(3.4V T
ypical)
TTL Low
(0.25V T
ypical)
10
µ
s
Minimum
