5-4 Rel, Math, Ratio, Channel Average, dB Model 2701 User’s Manual
Remote programming — rel
Rel commands
The rel commands to set range are listed in Table 5-1. Additional information on these
commands follow the table.
NOTE Query commands are not included in Table 5-1. All commands for the SENSe
subsystem are provided in Table 15-5.
Table 5-1
Rel commands
Commands
1
Description Default
Rel commands for DCV
[SENSe[1]] Optional root command.
:VOLTage[:DC]:REFerence <n> [, <clist>] Specify rel value; <n> = -1010 to 1010
(V).
0
:VOLTage[:DC]:REFerence:STATe <b>
[, <clist>]
Enable/disable rel; <b> = ON or OFF. OFF
:VOLTage[:DC]:REFerence:ACQuire [, <clist>] Use input signal as rel value.
Rel commands for ACV
[SENSe[1]] Optional root command.
:VOLTage:AC:REFerence <n> [, <clist>] Specify rel value; <n> = -757.5 to 757.5
(V).
0
:VOLTage:AC:REFerence:STATe <b> [, <clist>] Enable/disable rel; <b> = ON or OFF. OFF
:VOLTage:AC:REFerence:ACQuire [, <clist>] Use input signal as rel value.
Rel commands for DCI
[SENSe[1]] Optional root command.
:CURRent[:DC]:REFerence <n> [, <clist>] Specify rel value; <n> = -3.1 to 3.1 (A). 0
:CURRent[:DC]:REFerence:STATe <b>
[, <clist>]
Enable/disable rel; <b> = ON or OFF. OFF
:CURRent[:DC]:REFerence:ACQuire [, <clist>] Use input signal as rel value.
Rel commands for ACI
[SENSe[1]] Optional root command.
:CURRent:AC:REFerence <n> [, <clist>] Specify rel value; <n> = -3.1 to 3.1 (A). 0
:CURRent:AC:REFerence:STATe <b>
[, <clist>]
Enable/disable rel; <b> = ON or OFF. OFF
:CURRent:AC:REFerence:ACQuire [, <clist>] Use input signal as rel value.
