Model 2701 User’s Manual Getting Started 1-11
Front and rear panel familiarization (QS1)
Front panel summary
The front panel of Model 2701 is shown in Figure 1-1.
Figure 1-1
Model 2701 front panel
NOTE Most keys provide a dual function or operation. The nomenclature on a key indi-
cates its unshifted function/operation which is selected by pressing the key.
Nomenclature (in blue) above a key indicates its shifted function. A shifted func-
tion is selected by pressing the SHIFT key and then the function/operation key.
1 Special keys and power switch:
SHIFT Use to select a shifted function or operation.
LOCAL Cancels remote mode. SHIFT + LOCAL disables keyclick.
POWER Power switch. In position turns 2701 on (I), out position turns it off (O).
2 Function and operation keys:
Top Row
Unshifted
DCV Selects DC voltage measurement function.
ACV Selects AC voltage measurement function.
DCI Selects DC current measurement function.
ACI Selects AC current measurement function.
Ω2 Selects 2-wire resistance measurement function.
Ω4 Selects 4-wire resistance measurement function.
FREQ Selects frequency measurement function.
TEMP Selects temperature measurement function.
1
2
3
4
5
6
7
!
2701 ETHERNET MULTIMETER / DATA ACQUISITION SYSTEM
RANGE
F
500V
PEAK
FRONT/REAR
3A 250V
AMPS
HI
INPUT
LO
SENSE
Ω4 WIRE
INPUTS
350V
PEAK
1000V
PEAK
AUTO
SHIFT
LOCAL
POWER
RANGE
R
EXIT ENTER
DIGITS RATE
RELFILTER
TRIG
EX TRIG
STORE
RECALL
OPEN
DCV
DCI
MATH
OUTPUT
RATIO
ACV
ACI
Ω
2
Ω
4
FREQ
TEMP
CH AVG
CONT
PERIOD SENSOR
LIMITS ON/OFFDELAY
HOLD
SAVE SETUP
CONFIG HALT
TYPE
LSYNC
TEST
MONITOR
STEP SCAN
OCOMP
CH-OFF
CARD
CLOSE
INTEGRA SERIES
RS-232ETHERNET
CAT I
