15-6 SCPI Reference Tables Model 2701 User’s Manual
Table 15-3
FORMat command summary
Command Description
Default
parameter Ref SCPI
FORMat
:ELEMents <item list> Specify data elements (READing, CHANnel,
UNITs, RNUMber, TSTamp, and LIMits).
(see Note) Sec 14 ✓
:ELEMents? Query data elements. ✓
:SREGister <name> Select data format for reading status registers:
<name> = ASCii Decimal format
HEXadecimal Hexadecimal format
OCTal Octal format
BINary Binary format
ASCii
Sec 11 ✓
:SREGister? Query data format for reading status registers. ✓
Note: The SYSTem:PRESet and *RST default is READ, UNIT, RNUM, and TST.
Table 15-4
ROUTe command summary
Command Description
Default
parameter Ref SCPI
ROUTe
:MONitor <clist> Specify one channel to be monitored. Sec 7
:STATe <b> Enable or disable channel monitoring. OFF
:STATe? Query state of channel monitoring.
:DATA? Returns the most recent monitor reading.
:POINts <NRf> For a monitor scan, specify number of channels
to scan (2 to 450000).
(Note 1)
:POINts? For a monitor scan, query number of channels to scan.
:MONitor? Query the channel to be monitored.
:CLOSe <clist> Close the one specified channel (all others will
open).
Sec 2
:STATe? <clist> Query closed channels in specified list;
1 = closed.
:ACONfigure <b> Enable or disable auto-configure. (Note 2)
:ACONfigure? Query state of auto-configure.
:COUNt? <clist> Query closure count for specified channels. Sec 2
:INTerval <NRf> Set count update interval in minutes (10 to 1440). (Note 3)
:INTerval? Query relay count update interval.
:CLOSe? Returns a <clist> of closed channels.
:OPEN:ALL Open all channels. Sec 2

Keithley 2701 Specifications

General

Max Voltage	300 V
Max Current	3 A
Frequency Range	3 Hz to 500 kHz
Frequency Accuracy	0.01%
Weight	3.6 kg
Measurement Functions	Frequency, Temperature
Interface	IEEE-488 (GPIB), RS-232
DC Voltage Range	300 V
DC Current Range	3 A
AC Voltage Range	300V
AC Current Range	1 μA to 3 A
Resistance Accuracy	0.01%
Channels	10
Dimensions	213mm x 88mm x 370mm
