Model 2701 User’s Manual Getting Started 1-3
Safety symbols and terms
The following symbols and terms may be found on the instrument or used in this manual:
The symbol on an instrument indicates that the user should refer to the operating
instructions located in the manual.
The symbol on the instrument shows that high voltage may be present on the termi-
nal(s). Use standard safety precautions to avoid personal contact with these voltages.
The WARNING heading used in this manual explains dangers that might result in
personal injury or death. Always read the associated information very carefully before
performing the indicated procedure.
The CAUTION heading used in this manual explains hazards that could damage the
instrument. Such damage may invalidate the warranty.
Inspection
Model 2701 was carefully inspected electrically and mechanically before shipment. After
unpacking all items from the shipping carton, check for any obvious signs of physical
damage that may have occurred during transit. (There may be a protective film over the
display lens, which can be removed). Report any damage to the shipping agent immedi-
ately. Save the original packing carton for possible future shipment. The following items
are included with every Model 2701 order:
• Model 2701 with line cord.
• Safety test leads (Model 1751).
• Accessories as ordered.
• Hardware for rack mounting.
• Certificate of calibration.
• Model 2701 User’s Manual - PDF on CD-ROM.
• Model 2701 Instrument Networking Instruction Manual - Hard copy and PDF on
CD-ROM.
• Model 2701 Getting started foldout.
• Ethernet cross over cable (3-meters in length).
• Software CD containing the following:
• TestPoint Runtime – Provides basic data logging capabilities. This can be
modified with the TestPoint application development package (optional
software).
• KE2700 IVI Instrument Driver – Provided for programmers, designed for use
with application development environments.
Optional “Software” available from Keithley is summarized on page 1-6.
NOTE The Model 2701 Service Manual is a separate purchased part. Contact
Keithley’s Service Department to order this manual.
!
