Keithley 2701 User Manual

15-4 SCPI Reference Tables Model 2701 User’s Manual
CALCulate3 Subsystem to control CALC 3 (limit test): Sec 9 ✓
:MLIMit Path for master limit command:
:LATChed <b> Enable or disable master limit latch. OFF
:OUTPut Path for limit output commands:
[:STATe] <b> Enable or disable limit outputs. OFF
[:STATe]? Query state of limit outputs.
:PULSe Path to control limit output pulsing:
[:STATe] <b> Enable or disable limit output pulsing. OFF
[:STATe]? Query state of limit output pulsing.
:TIME <NRf> Set output pulse time in sec (0.001 to
99999.999).
0.002
:TIME? Query output pulse time.
:LSENse <name> Set logic sense of all limit lines (AHIGh or
ALOW).
AHIGh
:LSENse? Query logic sense of limit lines.
:LIMit1 Path to control LIMIT 1 test: ✓
:UPPer Path to configure upper limit: ✓
[:DATA] <n>
[, <clist>]
Set upper limit (-4294967295 to
+4294967295).
1 ✓
[:DATA]? [<clist>] Query upper limit. ✓
:LOWer Path to configure lower limit: ✓
[:DATA] <n>
[, <clist>]
Set lower limit (-4294967295 to
+4294967295).
-1 ✓
[:DATA]? [<clist>] Query lower limit. ✓
:STATe <b>
[, <clist>]
Enable or disable limit test. OFF ✓
:STATe? [<clist>] Query state of limit test. ✓
:FAIL? Query test result (1 = failing). ✓
:CLEAR Path to clear events: ✓
[:IMMediate] Clear high and low events. ✓
:AUTO <b> Enable or disable auto-clear. ON ✓
:AUTO? Query auto-clear. ✓
Table 15-1 (continued)
CALCulate command summary
Command Description
Default
parameter Ref SCPI

Keithley 2701 Specifications

General

Max Voltage	300 V
Max Current	3 A
Frequency Range	3 Hz to 500 kHz
Frequency Accuracy	0.01%
Weight	3.6 kg
Measurement Functions	Frequency, Temperature
Interface	IEEE-488 (GPIB), RS-232
DC Voltage Range	300 V
DC Current Range	3 A
AC Voltage Range	300V
AC Current Range	1 μA to 3 A
Resistance Accuracy	0.01%
Channels	10
Dimensions	213mm x 88mm x 370mm
