Model 2701 User’s Manual SCPI Reference Tables 15-15
[SENSe[1]]
:TEMPerature Path to configure temperature: Sec 3 ✓
:APERture <n> [, <clist>] Set integration rate in seconds
(3.333333e-5 to 1).
(Note 2) Sec 4
:APERture? [<clist>] Query aperture integration rate.
:NPLCycles <n> [, <clist>] Set integration rate in line cycles (60Hz;
0.002 to 60, 50Hz; 0.002 to 50).
5.0 Sec 4 ✓
:NPLCycles? Query line cycle integration rate. ✓
:DIGits <n> [, <clist>] Specify measurement resolution (4 to 7). 6 Sec 4
:DIGits? [<clist>] Query resolution.
:REFerence <n> [, <clist>] Specify reference in °C (-328 to 3310). 0 Sec 5 ✓
:STATe <b> [, <clist>] Enable or disable reference. OFF ✓
:STATe? [<clist>] Query state of reference. ✓
:ACQuire [, <clist>] Use input signal as reference.
:REFerence? [<clist>] Query reference value. ✓
:AVERage Path to configure and control filter: Sec 4
:TCONtrol <name> Select filter type: (MOVing or REPeat). (Note 3)
:TCONtrol? Query filter type.
:WINDow <NRf> Set filter window in % of range
(0 to 10).
0.1
:WINDow? Query filter window.
:COUNt <n> [, <clist>] Specify filter count (1 to 100). 10
:COUNt? [<clist>] Query filter count.
[:STATe] <b> [, <clist>] Enable or disable filter. (Note 4)
[:STATe]? [<clist>] Query state of digital filter.
:TRANsducer <name>
[, <clist>]
Select temperature transducer (TCouple,
FRTD, or THERmistor).
TCouple Sec 3
:TRANsducer? [<clist>] Query transducer type.
Table 15-5 (continued)
SENSe command summary
Command Description
Default
parameter Ref SCPI

Keithley 2701 Specifications

General

Max Voltage	300 V
Max Current	3 A
Frequency Range	3 Hz to 500 kHz
Frequency Accuracy	0.01%
Weight	3.6 kg
Measurement Functions	Frequency, Temperature
Interface	IEEE-488 (GPIB), RS-232
DC Voltage Range	300 V
DC Current Range	3 A
AC Voltage Range	300V
AC Current Range	1 μA to 3 A
Resistance Accuracy	0.01%
Channels	10
Dimensions	213mm x 88mm x 370mm
