Model 2701 User’s Manual KE2700 Instrument Driver Examples G-19
Name
Manual
Reference Brief Description
Simple7 None Use Case 7 — Ten 40-channel scans using 7702 module:
• Channel 1 uses an external reference junction.
• Measurement speed (rate) – 1 plc.
• Filter – Repeat, 25 readings.
• Channels 2 through 40 are connected to type K thermocouples.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 400 reading strings. Buffer elements include
reading only.
• Triggering – Bus control source.
Simple8 None Use Case 8 — 7706 module in slot 1 and 7702 module in slot 2:
• 7706 module:
• Output analog output values to analog output channels.
• Output digital output values to digital output channels.
• 7702 module:
• Scan 120 DCV channels.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 320 reading strings. Buffer elements include
reading only.
• Triggering – Bus control source, trigger delay 0.125 seconds.
Table G-2 (continued)
LabVIEW examples
