1-26 Getting Started Model 2701 User’s Manual
Setting Factory *RST Set Diff
RS-232 No effect No effect
Baud rate No effect No effect
Flow control No effect No effect
Terminator No effect No effect
Scanning Disabled Disabled
Auto scan No (off) No effect
Type (Simple or Advanced) No effect No effect
Simple scan
Minimum channel 101, 201, 301, 401, or 501 101, 201, 301, 401, or 501
Maximum channel No effect No effect
Timer Off Off
Reading count No effect No effect
Advanced scan
Setup No effect No effect
Immediate trigger On On
Limit triggers Off Off
Timer Off Off
Reading count No effect No effect
Temperature
Digits 5½ digits 5½ digits
Filter On Off
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat
Rate Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Sensor Thermocouple Thermocouple
Junction See Note See Note
Open detector No (off) No (off)
Type K K
Units °C °C
Timestamp No effect No effect
Triggering Continuous One-shot
Delay Auto Auto
Source Immediate Immediate
Reading hold Off Off
Window 1% 1%
Count 5 5
Table 1-4 (continued)
Default settings
