2Service
162 Keysight 53210A/53220A/53230A Assembly Level Service Guide
Figure 2-11 ac Power Supply Testpoint Locations on the Motherboard
assembly (top view, internal battery removed, test points
visible.)
Test Points
REAR
FRONT
Motherboard
