Keysight Technologies 53210A User Manual

1 Performance Tests
28 Keysight 53210A/53220A/53230A Assembly Level Service Guide
Equipment required
Table 1-1 Recommended test equipment for operational verification and
performance tests
Instrument Required characteristics Recommended model
Microwave signal generator
100 MHz to 15 GHz; Freq Accy at
6 GHz and 15 GHz:
±10ppb;
PW Accy: ±10%
Keysight E8257D-520-UNW or
equivalent
Pulse generator
5 nSec pulse width
±
40 pSec
Keysight 81134A or equivalent
RF signal generator
10 MHz ± 2.000E-12
Stanford Research Systems
CG635
Primary frequency standard
(10 MHz house standard)
Absolute accuracy >
1 x 10-10
Stanford Research Systems
FS725 Rubidium Timebase or
equivalent
DC power supply Adjustable to 5.000V Keysight 6234A or equivalent
Digital multimeter (DMM) Microvolt accuracy Keysight 34410A or equivalent
SMA(m)-to-BNC(f) adapters (3) Keysight 1250-1200
Type N(m)-to-BNC(f) adapter Keysight 1250-0780
BNC-to-dual banana plug BNC(f) to banana plug (m)
Keysight E9637A or Newark
10M4161
50 Ω coaxial cable with
BNC connectors (5)
BNC(m) to BNC(m), 48 inches Keysight 10503A
3.5mm cables (2) DC-18 GHz,matched pair Keysight 11500E
Coaxial BNC tee connector Keysight 1250-0781
