4 Retrofitting Options
232 Keysight 53210A/53220A/53230A Assembly Level Service Guide
To Retrofit the 53220A/53230A Channel 3 Input, 6.0 GHz
(Option 106) or 15.0 GHz (Option 115) plus Front panel option 202
Option 202 front panel channel 3 parts
Item Keysight part no. Qty.
Type N-to-SMA
connector-adapter
E4418-20009 1
Washer-plate (with "LIFT" tab) E4418-00016 1
14mm Hex nut 2950-0132 1
Hole plug 6960-0076 1
6.0 GHz Assembly (Option 106) 53200-66505 1
15.0 GHz assembly (Option 115) 53200-66506 1
RF cable, front, SMA semi-rigid 53200-61604 1
Ribbon cable, 40-pin 53200-61605 1
Labels, 6 GHz 53200-84301 2
Labels, 15 GHz 53200-84302 2
Standoff (Option 115 only) 0380-5091 2
Bracket, aluminum 53200-00603 1
TORX 10 screws 0515-0430 4
Screws, flathead 0515-1946 2
Screw (Option 115 only) 0515-31311 2
After the installation of Option 106 or 115, a complete microwave frequency
calibration must be performed. Refer to Chapter 2 for the procedure.
