Preliminary steps
1 Remove the instrument cover as follows:
2 To remove the counter handle, rotate the handle to the vertical (90 degree)
position and pull outward on the two side arms.
3 Using a T20 TORX screwdriver, loosen the two TORX screws securing the rear
panel bezel.
4 Slide the outside cover of the counter to the rear and remove the cover.
5 If installed, disconnect and move the Option 300 Internal Battery DC Power
Assembly out of the way as follows (refer to the figures in Chapter 4, "To
Retrofit the Internal Battery DC Power (Option 300)", as needed):
– Remove the two T20 TORX screws and lockwashers holding the Option 300
assembly to the left-hand side panel (as viewed from the rear of the
instrument).
– Lift up carefully on the left side of the assembly and remove the assembly
from the three large tabs holding it on the right side.
– Lay the assembly on its back to the right side of the chassis and place the
three small tabs on the back side of the three large tabs into the three slots
on the assembly deck. Disconnect the two cables going to the assembly.
Before proceeding with the installation, follow all the ESD steps as outlined
in the section titled Do This first under the Introduction at the beginning of
Chapter 4 of this service guide.
Refer as necessary to the illustrations in the section titled “To Remove the Cover
and Rear Bezel” on page 185 of this guide.
