Performance Tests 1
Keysight 53210A/53220A/53230A Assembly Level Service Guide 55
Test 4: (Q) Pulse width
This test uses the Keysight 53220A/53230A Counter to measure the width of a
narrow pulse from a pulse generator.
Equipment
– FS725 Rubidium timebase
– Keysight 81134A pulse generator
Keysight 10503 BNC cables (3)
– Keysight 15443A (SMA) cable or Keysight 11500E (3.5 mm) cable
– Keysight 1250-1200 BNC(f)-to-SMA(m) adapter (2)
81134A setup
– Output Level: 1 Vpp
– Period: 66.6 nSec
– Pulse Width: 5 nSec
NOTE
Test #4 applies to the 53220A and 53230A only.
