Performance Tests 1
Keysight 53210A/53220A/53230A Assembly Level Service Guide 67
3 Press the Channel 3 input key.
– Channel 3 is selected for test input.
4 Press the Gate key.
–The Gate softkeys are displayed:
5 Press and set:
– Gate Src: Timed
– Gate Out: On
–Gate Time: 10 mSec
6 Press the Trigger key.
–The Trigger softkeys are displayed:
There are no parameters to set for Channel 3 for this test.
