1046| Appendix
Feature Pa1000
SongBook Fully programmable music database, based on Styles, MIDI Songs
(MID and KAR files), MP3 Songs, with automatic selection of Style
Play and Song Play modes
User definable Set Lists, with Entries selectable from the control
panel
Filtering and sorting options
Compatibility Pa-Series models: Styles, Performances/Keyboard Sets, Programs/
Sounds, Songs, SongBook Entries, Pads
‘i-Series’ models: Styles
Pads Four Assignable Pads + Stop buttons
Pad Record function
General Controls Master Volume; Fade In/Out; Keyboard-Acc/Song Balance; Ensemble;
Octave Transpose; Master Transpose; Quarter Tone and Arabic Scale
memorized inside Keyboard Sets; Joystick; Audio In Volume; Mic FX
Level; Harmony/Double On/Off; Mic/Guitar Preset; Audio In Mute; 2
Assignable Knobs; 3 Assignable Switches; Tempo +/-; Tempo Lock;
Metronome On/Off; Dial; Search; Shift; Chord Scan (Lower, Upper);
Split; Track Select; Record
Scale Controls Virtual Quarter Tone SubScale Keypad, 4 x Scale Presets
Control Inputs Damper pedal (supports half-pedaling with the optional DS-1H pedal)
Assignable pedal/switch
Audio Inputs Line (Left/Right): 1/4” jacks, +20dBm, 12 kOhm
Mic/Guitar (Left): 1/4” jack, with Gain control (0 ~ +40dB)
12 kOhm (Mic) / 500 kOhm (Guitar)
Audio Outputs Left/Right, 1/4” jack, +21dBm, 0.003% THD+N@+18dBm
Headphone output (1/4” jack), 16-200 Ohms (50 Ohms suggested)
Speaker System Amplification: 2 x 33 W
Speakers: 2 x 100 mm woofers in bass reflex box, 2 x 25 mm dome
tweeters
MIDI IN, OUT standard MIDI connectors
USB to MIDI using the USB ports
Eight user definable MIDI Setups
USB Type A (HOST, for memory and controllers) x 2 (front/rear)
Type B (DEVICE, for personal computers and tablets) x 1 (rear)
2.0 Hgh-Speed connections (480 Mbit/s).
Storage Internal memory: 960 MB
USB external drives (drive not included)
microSD card (not included); rear panel slot with plastic cover
