Editing the Styles and Pads |283
3 Use the Event pop-up menu to choose the type of event to delete.
Event Meaning
All All events. The measures are not removed from the Chord Variation.
Note All notes in the selected range.
Dup.Note All duplicate notes. When two notes with the same pitch are encoun-
tered on the same tick, the one with the lowest velocity is deleted.
After Touch After Touch events.
Pitch Bend Pitch Bend events.
Prog.Change Program Change events, excluding the bundled Control Change #00
(Bank Select MSB) and #32 (Bank Select LSB).
This kind of data is automatically removed during recording.
Ctl.Change All Control Change events, for example Bank Select, Modulation,
Damper, Soft Pedal…
CC00/32 … CC127 Single Control Change events. Double Control Change numbers (like
00/32) are MSB/LSB bundles.
Some CC data are automatically removed during recording.
4 Use the Start Tick and End Tick parameters to set the beginning and ending
of the passage to be deleted.
If a Chord Variation is four measures long, and you want to select it all, the
Start will be positioned at 1.01.000, and the End at 5.01.000.
5 Use the Bottom Note and Top Note parameters to set key range to edit.
These parameters are available only when the All or Note option is selected.
If you select the same note as the Bottom and Top parameters, you can se-
lect a single percussive instrument in a Drum Kit. Selecting a range can also
be used to only edit RX Noises (from C7) or ordinary notes (under C7).
6 After having set the various parameters, touch Execute.
7 Press the START/STOP button to check how it works. Press START/STOP
again to stop playback.
