Korg PS60 Parameter Guide

IFX (Insert effects) List 053: Xctr-Comp (Exciter - Compressor)
111
053: Xctr-Comp (Exciter -
Compressor)
Thiseffectcombinesamonoexciterandacompressor.You
canchangetheorderoftheeffects.
054: Xctr- Lmtr (Exciter - Limiter)
Thiseffectcombinesamonoexciterandalimiter.Youcan
changetheorderoftheeffects.
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amount –100...+100
Sets the modulation
amount for Wet/Dry
Full
parameter
Quick
parameter
Value Explanation
Exciter
Exciter Blend X Blend –100...+100
Sets the intensity
(depth) of the Exciter
effect p.88
Emphasis
Freq
F Freq 0...70
Sets the frequency
range to be empha-
sized p.88
Pre EQ Trim 0...100
Sets the EQ input
level
[LEQ Gain
[dB]
–15...+15
Sets the gain of Low
EQ
HEQ Gain
[dB]
–15...+15
Sets the gain of High
EQ
Compressor
Sensitivity C Sens 1...100
Sets the sensitivity
p.83
Attack C Attack 1...100
Sets the attack level
p.83
Level C OutLevel 0...100
Sets the compressor
output level p.83
Routing Route
Xct→ Cmp,
Cmp → Xct
Switches the order of
the exciter and
compressor
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amount –100...+100
Sets the modulation
amount for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
+
Routing
Compressor
LEQ HEQ
EQ Trim
Comp
Output Level
Envelope - Control
Exciter
Exciter
Full
parameter
Quick
parameter
Value Explanation
Exciter
Exciter Blend X Blend –100...+100
Sets the intensity
(depth) of the Exciter
effect p.88
Emphasis
Freq
F Freq 0...70
Sets the frequency
range to be
emphasized p.88
Pre EQ Trim 0...100
Sets the EQ input
level
LEQ Gain
[dB]
–15...+15
Sets the gain of Low
EQ
HEQ Gain
[dB]
–15...+15
Sets the gain of High
EQ
Limiter
Ratio L Ratio
1.0 : 1...
50.0 : 1, Inf : 1
Sets the signal
compression ratio
p.110
Threshold
[dB]
L Trsh[dB] –40...0
Sets the level above
which the
compressor is applied
p.110
Attack L Attack 1...100 Sets the attack time
Release L Release 1...100 Sets the release time
Gain Adjust
[dB]
L G [dB]
–Inf,
–38...+24
Sets the limiter
output gain p.110
Routing Route
Xct → Lmt,
Lmt → Xct
Switches the order of
the exciter and limiter
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amount –100...+100
Sets the modulation
amount for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
+
Routing
LEQ HEQ
EQ Trim
Exciter
Exciter
Limiter
Limiter
Gain Adjust
Envelope - Control
