Korg PS60 Parameter Guide

LFO OSC1 LFO2
53
WhenAMSisatitsmaximumvalue(forexamplebymov‐
ingthejoystickfullyawayfromyourself),theAMSaffects
thefrequencyasshownbelow:
IntMod Src (Intensity Mod AMS)
[List of AMS Sources]
Thissele ctsasecondaryAMSsourcetoscaletheintensityof
AMS1.
ForalistofAMSsources,pleasesee“A l t e r n a t e Modulation
Source(AMS)”onpage 121.
IntMod Int [–99...+99]
Thiscontrolsthedepthanddirectionofthe“IntModSrc.”
EvenifthemainAMS1“Intensity”issetto0,“IntModSrc”
canstillcontrolthefinalamountofAMSAoverthefull+/–
99range.
Forexample,if“Source”issettothePitchEG,and“IntMod
Src
”issettoJS+Y:CC#01,positivesettingsmeanthatYS+Y
willincreasetheintensityofthePitchEGmodulationofthe
LFOFrequency.
AMS2
Source [List of AMS Sources]
ThisselectsthesecondAMSsourcefortheLFO1’s fre‐
quency.
ForalistofAMSsources,pleasesee“A l t e r n a t e Modulation
Source(AMS)”onpage 121.
Intensity [–99...+99]
Thiscontrolstheamountofmodulationfrom“Source.”
Frequency MIDI/Tempo Sync.
MIDI/Tempo Sync. [Off, On]
When“MIDI/TempoSync”isOn,theLFOwillsynchronize
tothesystemtempo,assetbyeithertheTempoorMIDI
Clock.TheLFOspeedwillbecontrolledbythe“BaseNote”
and“Times”parameters,below.Allsettingsfor“Fre‐
quency”andFrequencyModulationwillbeignored.
When“MIDI/TempoSync”isOff,th
e“Frequency”andFre‐
quencyModulationsettingswilldeterminethespeedofthe
LFO,andthetemposettingswillhavenoeffect.
Base Note [   ]
ThissetsthebasicspeedoftheLFO,relativetothesystem
tempo.Thevaluesrangefroma32ndnotetoawholenote,
includingtriplets.
Times [01...32]
ThismultipliesthelengthoftheBaseNote.Forinstance,if
the“BaseNote”issettoasixteenthnote,and“Times”isset
to03,theLFOwillcycleoveradottedeight hnote.
OSC1 LFO2
ThisisOscillator1’ssecondLFO.Itsparametersare exactly
thesameasthoseforthefirstLFO–exceptthatLFO1cannot
modulateLFO2.
)“OSC1LFO1”onpage 52
OSC2 LFO1
ThispagecontrolsOscillator2’sfirstLFO.Itisavailableonly
whentheOscillatorModeissettoDouble;ifnot,thepage
willbegrayedout.
TheparametersareidenticaltothoseforOscillator1.
)“OSC1LFO1”onpage 52
OSC2 LFO2
ThispagecontrolsOscillator2’ssecondLFO.Itisavailable
onlywhentheOscillatorModeissettoDouble;ifnot,the
pagewillbegrayedout.
Itsparametersareexactlythesameasthoseforthefirst
LFO–exceptthatLFO1cannotmodulateLFO2.
)“OSC1LFO1”onpage 52
Intensity Change to LFO Frequency
+99 64x
Faster
+82 32x
+66 16x
+49 8x
+33 4x
+16 2x
–16 1/2x
Slower
–33 1/4x
–49 1/8x
–66 1/16x
–82 1/32x
–99 1/64x

Korg PS60 Specifications

General

Type	Performance Synthesizer
Synthesis Type	Sample-based synthesis
Velocity Sensitivity	Yes
Aftertouch	No
Arpeggiator	Yes
Sequencer	No
MIDI	In, Out, Thru
Power Supply	DC 9V
Keyboard	61 keys
Sound Engine	EDS-i
Effects	2 Master effects
Controllers	Pitch bend, modulation wheel
Outputs	2 x 1/4" (L/R)
USB	Type B x 1
Sound Generator	EDS-i
Preset Programs	440 programs
Polyphony	120 voices (120 Oscillators)
Inputs	1 x 1/4" (damper)
