IFX (Insert effects) List 004: MulLimitr (Multiband Limiter)
85
Trigger Monitor
Turningthispa rameterOnwillcausethetriggersignaltobe
output,insteadoftheeffectsound.Usethisparameterto
checkthetriggersignalwithEQapplied.
Usually,thisshouldbesettoOff.
PEQ Insert
PEQ Cutoff [Hz]
Q
Gain [dB]
TheseparametersareusedtosettheEQamountthatʹs
appliedtothetriggersignal.
TheLimiterdetermineswhetherthecompressionisapplied
ornot,basedonthepost‐EQtriggersignal.Settingthe
equalizerallowsyoutosettheLimitertorespondtoany
frequencyband.
004: MulLimitr (Multiband Limiter)
ThiseffectappliestheLimitertothelowrange,midrange,
andhighrangeoftheinputsignal.Youcancontrol
dynamicsforeachrangetoadjustthesoundpressureofthe
lowrange,midrange,andhighrangeinadifferentway
fromtheEQ.
Low Offset [dB]
Mid Offset [dB]
High Offset [dB]
Theseparameterssetthegainofthetriggersignal.
Forexample,ifyoudonotwanttoapplycompressiontothe
highrange,reducethe“HighOffset”valuedownbelowthe
“Threshold”level.Inthisway,thehighrangelimiterwill
notrespond,andcompressionwillnotbeapplied.
005: St.MstLmt
(Stereo Mastering
Limiter)
Thisisastereolimiterthatisoptimizedformasteringsongs.
006: St.Gate (Stereo Gate)
Thiseffectmutestheinputsignalwhenitfallsbelowa
specifiedlevel.Youcan also inverttheon/offstatusofthe
gate,orusenote‐on/offmessagestoturnthegateon/off
directly.
Full
parameter
Quick
parameter
Value Explanation
Ratio ←
1.0 : 1...50.0 : 1,
Inf : 1
Sets the signal
compression ratio
p.84
Threshold
[dB]
Thresh[dB] –40...0
Sets the level above
which the
compressor is applied
p.84
Attack ← 1...100
Sets the attack time
p.84
Release ← 1...100
Sets the release time
p.84
Low Offset
[dB]
LowOfs[dB] –40...0
Gain of the low-range
trigger signal p.85
Mid Offset
[dB]
MidOfs[dB] –40...0
Gain of the mid-range
trigger signal p.85
High Offset
[dB]
HiOfs[dB] –40...0
Gain of the high-
range trigger signal
p.85
Gain Adjust
[dB]
Gain [dB]
–Inf,
–38...+24
Sets the output gain
p.84
Source Off...Tempo
Selects the
modulation source
for the output gain
Amount –63...+63
Sets the modulation
amount of the output
gain
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amount –100...+100
Sets the modulation
amount for Wet/Dry
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
Gain Adjust
Mid Offset
Low Offset
High Offset
Envelope - Control
Envelope - Control
Envelope - Control
Low
Mid
High
Band-Pass Filters
+
Limiter
Limiter
Limiter
Full
premiered
Quick
parameter
Value Explanation
Threshold
[dB]
Trsh[dB] –30.0...0.0
Sets the level above
which the
compressor is applied
p.84
Out Ceiling
[dB]
Cell [dB] –30.0...0.0 Sets the output gain
Release [ms] Rel[ms] 0.50...1000.0
Sets the release time
p.84
Wet/Dry ←
Dry, 1 : 99...
99 : 1, Wet
Sets the balance
between the effect
and the dry input
Source Off...Tempo
Selects a modulation
source for Wet/Dry
Amount –100...+100
Sets the modulation
amount for Wet/Dry
Full
premiered
Quick
parameter
Value Explanation
Envelope
Source
Env Src
D-mod,
Input,
FX Control 1,
FX Control 2
Selects the source to
control the gate: D-
mod control, or use
the input signal or FX
Control Bus 1 or 2 as a
trigger p.84
Fx Control
Trim
0...100
Sets the trigger input
level from FX Control
Bus 1/2
Envelope
L/R Mix,
L Only,
R Only
Selects the control
signal: left and right
linked, left only, or
right only p.84
Mid Source Off...Tempo
Selects the source
that will control the
gate when Envelope
Src = D-mod
Left
Right
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Limiter
Limiter
Out Ceiling
Out Ceiling
Envelope - Control
+
Left
Right
FX Control BUS 1
FX Control BUS 2
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Envelope Source
Gain Adjust
Gain Adjust
Side PEQ
Envelope - Control
Envelope - Control
Trigger Monitor
+
Envelope Select
Gate
Delay
Gate
Delay
D
-mod
