Korg PS60 - Page 146

Appendices
142
2
2.RECOGNIZED RECEIVE DATA
2-1 CHANNEL MESSAGES
[H] :Hex, [D] :Decimal
|[Hex] | [H][D] [H][D] | | |
Status Second | Third | Description ( Use ..... ) |ENA |
[Hex] [H] [D] | [H] [D] |
8n kk (kk)| xx (xx) | Note Off A |
9n kk (kk)| 00 (00) | Note Off A |
9n kk (kk)| vv (vv) | Note On (vv) = 1-127 A |
An kk (kk)| vv (vv) | Poly Key Pressure ( as AMS ) T |
Bn 01 (01)| vv (vv) | Modulation1 ( as Joy Stick +Y ) C |
Bn 02 (02)| vv (vv) | Modulation2 ( as Joy Stick -Y ) C |
Bn 04 (04)| vv (vv) | Foot Pedal ( as AMS & FX Dmod Src = Foot Pedal ) C |
Bn 05 (05)| vv (vv) | Portamento Time C |
Bn 06 (06)| vv (vv) | Data Entry (MSB) ( for RPC edit ) C |
Bn 07 (07)| vv (vv) | Volume C |
Bn 08 (08)| vv (vv) | Balance Control ( for Post IFX Panpot control ) *2 C |
Bn 0A (10)| vv (vv) | Panpot C |
Bn 0B (11)| vv (vv) | Expression C |
Bn 0C (12)| vv (vv) | Effect Control 1 ( as FX Dmod Src = Fx Control1 ) C |
Bn 0D (13)| vv (vv) | Effect Control 2 ( as FX Dmod Src = Fx Control2 ) C |
Bn 10 (16)| vv (vv) | Multi Purpose Ctrl1 ( as AMS & FX Dmod Src = CC#16(Rbn) ) C |
Bn 11 (17)| vv (vv) | Multi Purpose Ctrl2 ( as AMS & FX Dmod Src = Knob Mod1 CC#17 ) C |
Bn 12 (18)| vv (vv) | Multi Purpose Ctrl3 ( as AMS & FX Dmod Src = CC#18(Val ) C |
Bn 13 (19)| vv (vv) | Multi Purpose Ctrl4 ( as AMS & FX Dmod Src = Knob Mod2 CC#19 ) C |
Bn 14 (20)| vv (vv) | ( as AMS & FX Dmod Src = Knob Mod3 CC#20 ) C |
Bn 15 (21)| vv (vv) | ( as AMS & FX Dmod Src = Knob Mod4 CC#21 ) C |
Bn 26 (38)| vv (vv) | Data Entry (LSB) ( for RPC edit ) C |
Bn 40 (64)| vv (vv) | Hold1 ( as Damper) C |
Bn 41 (65)|
3F/
40 (
63/
64) | Portamento Off/On C |
Bn 42 (66)|
3F/ 40 (
63/
64) | Sostenuto Off/On C |
Bn 43 (67)| vv (vv) | Soft Pedal C |
Bn 46 (70)| vv (vv) | Sound Controller 1 ( for Sustain Level control ) C |
Bn 47 (71)| vv (vv) | Sound Controller 2 ( for Resonance control ) C |
Bn 48 (72)| vv (vv) | Sound Controller 3 ( for Release Time control ) C |
Bn 49 (73)| vv (vv) | Sound Controller 4 ( for Attack Time control ) C |
Bn 4A (74)| vv (vv) | Sound Controller 5 ( for Filter Cutoff control ) C |
Bn 4B (75)| vv (vv) | Sound Controller 6 ( for Decay Time control ) C |
Bn 4C (76)| vv (vv) | Sound Controller 7 ( for LFO1 Speed control ) C |
Bn 4D (77)| vv (vv) | Sound Controller 8 ( for LFO1 Pitch Depth control ) C |
Bn 4E (78)| vv (vv) | Sound Controller 9 ( for LFO1 Delay control ) C |
Bn 4F (79)| vv (vv) | Sound Controller 10 ( for Filter EG Intensity control ) C |
Bn 50 (80)| vv (vv) | Multi Purpose Ctrl5 ( as AMS & FX Dmod Src = CC#80 ) C |
Bn 51 (81)| vv (vv) | Multi Purpose Ctrl6 ( as AMS & FX Dmod Src = CC#81 ) C |
Bn 52 (82)| vv (vv) | Multi Purpose Ctrl7 ( as AMS & FX Dmod Src = Foot Switch ) C |
Bn 53 (83)| vv (vv) | Multi Purpose Ctrl8 ( as AMS & FX Dmod Src = CC#83 ) C |
Bn 55 (85)| vv (vv) | ( as AMS & FX Dmod Src = CC#85 ) C |
Bn 56 (86)| vv (vv) | ( as AMS & FX Dmod Src = CC#86 ) C |
Bn 57 (87)| vv (vv) | ( as AMS & FX Dmod Src = CC#87 ) C |
Bn 58 (88)| vv (vv) | ( as AMS & FX Dmod Src = CC#88 ) C |
Bn 5B (91)| vv (vv) | Effect 1 Depth ( for Send 2 Level control ) C |
Bg 5C (92)| 00/
00 (00/
000) | Effect 2 Depth ( for All Insert FX Off/On ) C |
Bn 5D (93)| vv (vv) | Effect 3 Depth ( for Send 1 Level control ) C |
Bg 5E (94)| 00/
00 (00/ 000) | Effect 4 Depth ( for Master FX1,2 Off/On ) C |
Bg 5F (95)| 00/
00 (00/ 000) | Effect 5 Depth ( for EQ Off/On ) C |
Bn 60 (96)| 00 (00) | Data Increment ( for RPC edit ) C |
Bn 61 (97)| 00 (00) | Data Decrement ( for RPC edit ) C |
Bn 64(100)| 0r (0r) | RPN Param No. (LSB) ( for RPN select ) *3 C |
Bn 65(101)| 00 (00) | RPN Param No. (MSB) ( for RPN select ) *3 C |
Bn 78(120)| 00 (00) | All Sound Off C |
Bn 79(121)| 00 (00) | Reset All Controllers C |
Bn 7A(122)| 00/7F (00/127) | Local Control Off/On A |
Bn 7B(123)| 00 (00) | All Notes Off A |
Bn 7C(124)| 00 (00) | Omni Mode Off ( as All Notes Off ) A |
Bn 7D(125)| 00 (00) | Omni Mode On ( as All Notes Off ) A |
Bn 7E(126)| 10 (
16) | Mono Mode On ( as All Notes Off ) A |
Bn 7F(127)| 00 (00) | Poly mode On ( as All Notes Off ) A |
Cn pp (pp)| -- -- | Program Change ( for Performance change ) *1 P |
Dn vv (vv)| -- -- | Channel Pressure ( as AMS & FX Dmod Src = After Touch ) T |
En bb (bb)| bb (bb) | Bender Change C |
