130
1) If you specify SFX_A* and execute loading, the following
files will be loaded.
SFX_A_00.WAV, SFX_A_01.WAV
2) If you specify SFX_?_00 and execute loading, the follow-
ing files will be loaded.
SFX_A_00.WAV, SFX_B_00.WAV, SFX_C_00.WAV
3) If you specify SFX_*_00 and execute loading, the result
will be the same as if you had specified “SFX_*” and the
following files will be loaded.
SFX_A_00.WAV, SFX_A_01.WAV, SFX_B_00.WAV
SFX_B_01.WAV, SFX_C_00.WAV
4) If you specify * and execute loading, all .WAV files will
be loaded, as follows.
PIANO.WAV, SFX_A_00.WAV, SFX_A_01.WAV,
SFX_B_00.WAV, SFX_B_01.WAV, SFX_C_00.WAV
21) Load .KSC: selected icon
The .KMP files and .KSF files listed in the .KSC file will be
loaded as multisamples and samples respectively.
The .KMP files and .KSF files listed in the .KSC file
are saved in a directory of the same name that is cre-
ated automatically at the same time as the .KSC file.
1 “.KSC Allocation” allows you to specify how the multi-
samples and samples in the .KSC file will be loaded.
Append: The multisamples and samples will be loaded
following the last multisample or sample number that
already exists in the memory of the TRITON-Rack (i.e.,
by having been sampled or loaded). The valid multisam-
ples and samples that are loaded at this time will be
packed into consecutive numbers. (
☞p.126 “.SNG Allo-
cation” diagram in “Load .SNG too”)
If “Load
********
.PCG too” is checked when you load the
data, programs within the .PCG file that use multisam-
ples from the .KSC file will automatically have the multi-
sample settings for their oscillators rewritten so that each
program uses the correct multisample. Drum kits in the
.PCG file that use samples from the .KSC file will auto-
matically have the sample settings for the drum kit
rewritten so that the drum kit uses the correct samples.
Clear: All multisamples and samples currently in mem-
ory will be erased, and the multisamples and samples
will be loaded in the same configuration in which they
were saved (
☞p.126 “.SNG Allocation” diagram in “Load
.SNG too”).
If memory already contains multisamples or samples
that you wish to keep, and you wish to load additional
multisamples or samples from disk, select Append.
If the power has just been turned on, or you want to
reproduce the state that was saved, select Clear.
2 If the current directory contains a .PCG file or .SNG file of
the same filename, you will be able to select the “Load
********
.PCG too” and/or “Load
********
.SNG too” check-
boxes.
• If you check “Load
********
.PCG too,” the .PCG file of
the same name as the .KSC file will also be loaded.
• If you check “Load
********
.SNG too,” the .SNG file of
the same name as the .KSC file will also be loaded.
☞ “Load.SNG: 3”
3 To load the data, press the [F8] (“OK”) key. To cancel
without loading, press the [F7] (“Cancel”) key.
If the .KSF files used by the .KMP file are not in the cur-
rent directory or below it, a dialog box will appear, allow-
ing you to specify the directory. Use the procedure “If the
file to load cannot be found,…” (
☞p.125) to load the
required .KSF files.
Since PCM memory overflow checking is performed
when loading each .KSF file, an overflow may occur
during the loading process.
22) Load .KMP: selected icon
The selected .KMP file will be loaded as a multisample. The
.KSF files used by the .KMP will also be loaded as samples.
The .KSF files used by the .KMP file will be saved in
an identically-named directory that is created auto-
matically when the .KMP file is created.
1 To load the data, press the [F8] (“OK”) key. To cancel
without loading, press the [F7] (“Cancel”) key.
Samples will be loaded starting at the first unoccupied
number following the last multisample or sample that
currently exists in TRITON-Rack’s memory by having
been sampled or loaded. Only valid multisamples or
samples will be loaded (Append load).
If the .KSF files used by the .KMP file are not in the cur-
rent directory or below it, a dialog box will appear, allow-
ing you to specify the directory. Use the procedure “If the
file to load cannot be found,…” (
☞p.125) to load the
required .KSF files.
Since PCM memory overflow checking is performed
when loading each .KSF file, an overflow may occur
during the loading process.
23) Load .KSF: selected icon
The selected .KSF file will be loaded as a sample.
1 To load the data, press the [F8] (“OK”) key. To cancel
without loading, press the [F7] (“Cancel”) key.
The sample will be loaded following the last multisample
or sample that currently exists in the TRITON-Rack’s
memory by having been sampled or loaded (Append
load).
Loading AIFF files and WAVE files
The TRITON-Rack can load AIFF format or WAVE format
files, which are formats used to save audio data on personal
computers etc. The loaded data can be used as a sample.
24) Load .AIF: selected icon
The selected AIFF file will be loaded as a sample.
1 To load the data, press the [F8] (“OK”) key. To cancel
without loading, press the [F7] (“Cancel”) key.
The sample will be loaded following the last-numbered
sample that currently exists in memory by having been
sampled or loaded (Append load).
To Next Page
