LeeBoy 6150 - Page 203

Front Steering Assembly
Item
No
Part Number Qty Description Remarks
1 1016038 1 Tie Rod Assembly
2 20311908 1 Spindle Weldment - Left
3 20309381 1 Spindle Weldment - Right
4 1017109 2 Front Bogie Wheel Assembly
5 1015952 1 Hydraulic Cylinder w/Sensor, 2.50 x 1.06 x 6.00
6 6801-6-6 NWO 2 Elbow Adapter, 90°, -6 JIC / -6 O-Ring
7 2701-6-6-LN 2 Bulkhead Elbow Adapter, 90°, -6 JIC / -6
8 100-12-16-40-5 2 CSHH, 3/4-16 x 2.50, GR5
9 300-12 2 Washer, Flat, SAE, 3/4
10 202-12-16-5 2 Nut, Hex, Jam, 3/4-16, GR5
11 21005780 2 King Pin
12 20930707 4 Bearing Cup
13 20930335 4 Bearing Cone
14 20986386 2 Take-Up Sleeve
15 95997672 2 Castle Nut, 1-1/8"
16 95997862 2 Cotter Pin
17 20930996 2 Bearing Assembly
18 20930715 2 Bearing Cup
19 20930327 2 Bearing Cone
20 20930970 2 Tabbed Washer
21 95200986 2 Lock Washer
22 95200887 2 Locknut
23 20942520 2 Hub Cap
24 20934832 2 1/8 Lube Fitting
25 50270248 2 Cap
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-9
