LeeBoy 6150 - System Info; Lamp Info

4
LeeBoy 6150 Conveyor Paver 4-9
Operation
Lamp Info
This screen shows the Diesel Particulate Filter (DPF)
Lamp symbols and provides a description along with
cautionary information for each symbol. Use the UP/
DOWN soft keys to scroll to each symbol. (Figures
4-13 to 4-16)
Figure 4-13. High Exhaust Temperature Due to DPF
Regeneration Symbol Screen
Figure 4-14. Needs Regenerating Screen
System Info
Scroll through the Menu list using the UP/DOWN soft
keys, then press the select ( ) soft key when the cur-
sor (>) points to the desired information. (Figure 4-11)
The screen displays the engine model, serial number,
ECU Software ID, fuel rate, and the amount of time since
the last active regeneration process was performed.
Figure 4-11. System Info Screen
Press the UP/DOWN soft keys to scroll to the screen
with application and conguration information. (Figure
4-12)
Figure 4-12. Application and Conguration
Information Screen
