HYDRAULIC HOSE SCHEDULE - STANDARD UNIT
Hose
No.
Qty. Part Number Description
GRP 1 1016211 Main Hose Kit
1 1 K811HT0606161616-31 MIDDLE TANK TO REAR PUMP
2 1 K811HT0606161616-21 RIGHT TANK TO FRONT PUMP
3 1 F487TC6A39121212-60 PROPEL C TO RIGHT MOTOR REAR
4 1 F487TC6A39121212-45 PROPEL D TO RIGHT MOTOR FRONT
5 1 F487TC6A06121212-41 TOP BLKHD TO LEFT MOTOR REAR
6 1 F487TC6A06121212-26 BTM BLKHD TO LEFT MOTOR FRONT
7 1 F487TC0639121212-62 PROPEL B TO TOP BLKHD
8 1 F487TC0639121212-65 PROPEL A TO BTM BLKHD
9 1 F387TC0606040404-38 X7 TEE TO RIGHT BRAKE
10 1 F387TC0639040404-63 X7 TEE BTM TO TOP CNTR BLKHD
11 1 F387TC0606040404-23 TOP BLKHD TO LEFT BRAKE
12 1 F387TC0606101010-68 CHARGE FILTER TO PROPEL PUMP
13 1 F387TC0606060606-44 STEER CYL RIGHT TO TOP BLKHD
14 1 F387TC0637060606-37 STEER CYL LEFT TO BTM BLKHD
15 1 F387TC0606060606-40 STEER TOP BLKHD TO FRONT FRAME BLKHD
16 1 F387TC0606060606-43 STEER BTM BLKHD TO REAR FRAME BLKHD
17 2 F387TC0637060606-18 STEER MANIFOLD TO FRAME BLKHD
18 2 F387TC0606060606-26 HOPPER MAN TO FRAME BLKHD
19 2 F387TC0606060606-56 HOPPER BLKHD CROSSOVER
20 2 F387TC0606060606-59 HOPPER BLKHD TO LOWER CYL
21 2 F387TC0606060606-74 HOPPER BLKHD TO UPPER CYL
22 1 F387TC0606060606-82 REAR PUMP AUX TO STEER MAN P
23 1 F387TC0606040404-80 RIGHT MTR X1 TO BTM CNTR BLKHD
24 1 F387TC0606040404-18 BTM CNTR BLKHD TO LEFT MTR X1
25 1 F387TC0606040604-20 LWR MAN T3 STEER RETURN TEE
26 1 F387TC0606040404-28 LWR MAN 2SPA TO BTM CNTR BLKHD
27 1 F387TC0639060806-9 STEER RET TEE TO LWR MAN T2 TEE
28 1 F387TC0606080808-67 LWR MAN T2 TEE TO RET MAN LEFT
29 1 F387TC0606101010-42 LWR MAN T TO CHARGE FLTR
30 1 F387TC0639101010-90 FRONT PUMP P TO LWR MAN P2
31 1 F387TC0606121212-55-AS-B-19-51 PROPEL PUMP DRN TO RAD BTM
Hose
No.
Qty. Part Number Description
GRP 1 1016731 Hose Kit (Pre-Paint_
1 6 F5600101020203-73 HOSE ASSEMBLY, HYDRAULIC, GP-3000 PSI, -2MP/-2MP, 73"
2 4 F5600101020203-92 HOSE ASSEMBLY, HYDRAULIC, GP-3000 PSI, -2MP/-2MP, 92"
Illustrated Parts List
LeeBoy 6150 Conveyor Paver7-156
