LeeBoy 6150 - Single-Point Lube Kits

4
LeeBoy 6150 Conveyor Paver 4-39
Operation
Auger Lube Kit
The Auger Lube Kit combines the four (4) auger bear-
ings grease points into one lubrication point, located on
the back of the auger in front (left) of the right operator
station. (Figure 4-83)
Auger Lube Kit
Lubication Point
Figure 4-82. Auger Lubrication Point
Single-Point Lube Kits
The optional Single-Point Lube Kits offer the ability to
combine multiple lubrication points into one centralized
grease point. Individual grease points are combined
into one location for convenient machine lubrication and
more efcient paver maintenance. When you input the
grease into the central point, a valve distributes grease
evenly to all bearings. (Figure 4-81) A Conveyor Lube
Kit and an Auger Lube Kit are available options.
Figure 4-80. Conveyor Lube Valve
Conveyor Lube Kit
The Conveyor Lube Kit combines the 10 conveyor bear-
ing grease points and the two (2) front wheel spindle
bearings. This kit combines these 12 individual grease
points into one lubrication point located beside the fuel
ller cap. (Figure 4-82)
Conveyor Lube Kit
Lubication Point
Fuel Cap
Figure 4-81. Conveyor Lubrication Point
