LeeBoy 6150 - Lower Manifold Harness; Hydraulic Cooler Harness

Control Box Assembly (2 of 2)
Item
No
Part Number Qty Description Remarks
37 989178 1 Connector, 3 Pin, Y Socket
38 1000649 2 Connector, 3 Pin, DT06-3S-EP11
39 983210 2 Wedge Connector Plug, 3 Pin
40 1017346 1 Decal - Fuse Diagram
41 685060 1 Fuse Block, 18 Gang, ATC
REF 36746 1 Fuse, 5A, ATC
REF 36340 10 Fuse, 10A, ATC
REF 36341 2 Fuse, 15A, ATC
REF 36342 4 Fuse, 20A, ATC
REF 37303 1 Fuse, 25A, ATC
42 986546 1 Circuit Breaker, 10A w/Mount
43 1007228-03 1 Panel w/Notch
HARNESS LIST
REF 1016315 1 Main Harness Not Shown
REF 1016536 1 Lower Manifold Harness Not Shown
REF 1016263 1 Jumper C4 Dash To Pedestal Harness Not Shown
REF 1016264 1 Jumper C3 Dash To Pedestal Harness Not Shown
REF 1016682 1 Hydraulic Cooler Harness Not Shown
REF 1016537 1 Generator Valve Adapter Harness Not Shown
REF 1008877 1 Jumper Heater Element Harness Not Shown
REF 1017986 1 Power Crown Harness Not Shown
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-61
