Hose
No.
Qty. Part Number Description
32 1 F387TC0641121212-120 RAD TOP TO HYD TANK REAR RIGHT
33 1 F387TC0637121212-60 RIGHT MTR L2 TO RET MAN RIGHT TEE
34 1 F387TC0637121212-60 LEFT MTR L1 TO RET MAN LEFT END
35 1 F387TC0641080808-135 LWR MAN RA TO RIGHT TUBE
36 1 F387TC0606080808-135 LWR MAN RAT TO RIGHT TUBE
37 1 F387TC0641080808-115 LWR MAN LAT TO LEFT TUBE
38 1 F387TC0606080808-115 LWR MAN LA TO LEFT TUBE
40 1 F387TC0639080808-96 LWR MAN RCT TO RIGHT CONV MTR REAR
41 1 F387TC0641080808-96 LWR MAN RC TO RIGHT CONV MTR FRONT
42 1 F387TC0639080808-66 LWR MAN LCT TO LEFT CONV MTR REAR
43 1 F387TC0641080808-71 LWR MAN LC TO LEFT CONV MTR FRONT
44 1 F387TC0639101010-18 LWR MAN C TO HI PRES FLTR IN
45 1 F387TC06L9101010-22 HI PRES FLTR OUT TO UP MAN P
46 2 F387TC0606060606-120 UP MAN REA/B TO LEFT TUBE
47 1 F387TC0606060606-115 UP MAN LEA/B TO LEFT TUBE
48 1 F387TC0606040404-130 UP MAN RCA TO RIGHT CUTOFF FRONT
49 1 F387TC0606040404-132 UP MAN RCB TO RIGHT CUTOFF REAR
50 1 F387TC0606040404-77 UP MAN LCA TO LEFT CUTOFF FRONT
51 1 F387TC0606040404-80 UP MAN LCB TO LEFT CUTOFF REAR
52 1 F387TC0606060606-100 UP MAN S1 TO LEFT SL CYL BTM
53 1 F387TC0606060606-68 LEFT SL CYL TOP TO RET MAN TOP CEN TEE
54 1 F387TC0606060606-130 UP MAN S2 TO RIGHT SL CYL BTM
55 1 F387TC0606060606-78 RIGHT SL CYL TOP TO RET MAN TOP CEN TEE
56 2 F387TC0639040404-13 POSI-TRAC FRONT TO PROPEL PUMP MA/MD
57 2 F387TC0639040404-15 POSI-TRAC REAR TO PROPEL PUMP MB/MC
58 2 K811HT0637161616-16 AUX COOLER TO RET MAN RIGHT/TANK LEFT
59 1 F387TC0606101010-75 UP MAN T TO RET MAN TOP LH TEE
60 1 F387TC0641080808-118 LWR MAN V TO LH VIB MTR TOP
61 1 F387TC0641080808-154 LWR MAN VT TO RH VIB MTR TOP
62 1 F387TC0606080808-37-AS-B-15-34.5 LH VIB MTR BTM TO RH VIB MTR BTM
63 1 F387TC0606040404-33-AS-B-11-30.75 LH VIB MTR DRN TO RH VIB MTR DRN
64 1 F387TC0637040404-57-AS-B-11-54.75 LH VIB MTR DRN TO RET MAN LEFT
Hose
No.
Qty. Part Number Description
GRP 1 1015125 8520 Main Screed Hose Kit
84/85 2 F387TC0606060606-27-AS-B-13-24 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX, 27”
86/87 2 F387TC0606060606-80-AS-B-13-77 HOSE ASSEMBLY, HYDRAULIC, 3000 PSI, -6FJX/-6FJX, 80”
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-157
