LeeBoy 6150 - Page 207

Item
No
Part Number Qty Description Remarks
1 1006674 2 Front Chain Guard - Right
2 1006673 2 Front Chain Guard - Left
3 1016027 4 Conveyor Chain Cover
4 100-8-13-28-5 22 CSHH, 1/2-13 x 1.75, GR5
5 302-8 22 Washer, Lock, 1/2
6 100-8-13-32-5 11 CSHH, 1/2-13 x 2.00, GR5
7 204-8-13-5 19 Nut, Lock, Stover, 1/2-13, GR5
8 1016030 4 Conveyor Floor
9 1007053 2 Conveyor Front Sprocket Assembly Includes Items 10-16
10 1008919SRV 2 Conveyor Idler Weldment Includes Item 11 (x4)
11 850130 16 Insert Bearing, 1.50
12 985011 2 Conveyor Idler Shaft
13 1008923SRV 4 Conveyor Idler Sprocket Weldment
14 100-10-11-18-8F 4 CSHH, 5/8-11 x 1.125, GR8, FT
15 302-10 A/R Washer, Lock, 5/8
16 120360 4 Washer, Flat, 5/8 x 2.25 x .188
17 1007051 2 Conveyor Adjustment Clamp Plate
18 100-10-11-28-5 A/R CSHH, 5/8-11 x 1.75, GR5
19 300-10 A/R Washer, Flat, SAE, 5/8
20 200-10-11-5 8 Nut, Hex, 5/8-11, GR5
21 1007057SRV 2 Rear Axle Housing Includes Item 11 (x4)
22 1007061 2 Conveyor Drive Shaft
23 1007060SRV 2 Outer Sprocket Assembly
24 1007062SRV 2 Inner Sprocket Assembly
Conveyor Assembly (1 of 3)
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-13
