Item
No
Part Number Qty Description Remarks
1 1016029 2 Conveyor Chain, 2.6 Pitch x 99 x 22.31 Wide Includes Items 2-7
2 850080B A/R Conveyor Chain Link w/Tab
3 1007052-01 A/R Conveyor Drag Bar
4 851118-1 A/R Roll Pin, .375 x 2.00
5 850070A A/R Conveyor Chain Master Link
6 850100A A/R Conveyor Chain T-Pin
7 850080A A/R Conveyor Link w/o Tab
8 850162 8 Conveyor Chain Idler Roller
9 850040 8 Conveyor Drive Shaft Snap Ring
10 850215A 4 Conveyor Chain Offset Link
Conveyor Assembly (2 of 3)
7
Illustrated Parts List
LeeBoy 6150 Conveyor Paver 7-15
